| Voltage | 230/400V/D/Y, 50Hz |
| Efficiency class | IE3 (Premium Efficiency) |
| Rated current at 400V | 2,7 A |
| Efficiency at 100% nominal load | 84,1 % |
| Rated power | 1,1 kW |
| Rated speed | 1440 rpm |
| Protection class | IP66 |
| Type of protection | Zone 1/21 II 2G Ex db IIC T4 Gb / II 2D Ex tb IIIC T135 Db |
| Insulation class | F |
| Operating mode | S1 (continuous operation) |
| IEC size | 90S |
| Design | B35 |
| Terminal box position | top |
| Flange size | A200 |
| Shaft end (dxL) | 24x50 mm |
| Bearing d side | 6205-2Z |
| Bearing n-side | 6205-2Z |
| Color | blank aluminium |
| housing | Aluminium |
| Weight | 17,00 Kg |
Product description
Three-phase asynchronous motor with "flameproof enclosure" type of protection for use in potentially explosive atmospheres with gas or dust atmospheres in zones 1 or 21.
Features
Scope of delivery
Thank you very much! Your message was successfully sent.
This product can be configured. The selected options are displayed in the order information and the product price and delivery time are updated automatically.
Notes on option selection (German only) (other options available on request)
