KEB S32A DM100LF4 - Worm gearbox with three-phase motor ++ EMM

Name: Worm gear motor
Brand: KEB
SKU: 15528
Price: 1617.21 EUR
Availability: InStock

Worm gear motor

Manufacturer/Type: KEB S32A DM100LF4

Item no: 15528

Selected configuration

Reconfigure

1.359,00 EUR

1.617,21 EUR incl. VAT plus Shipping costs

Quantity

Technical data

Voltage	see selected configuration
Efficiency class	IE3 (Premium Efficiency)
Efficiency at 100% nominal load	87,7 %
Rated current (at standard voltage)	10,70/6,20 A
Rated power	3,0 kW
Output speed	59 rpm
Output torque	425 Nm
translation ratio i	24,49
Gear coefficient cG	1,25
Protection class	see selected configuration
Insulation class	F
Operating mode	S1 (continuous operation)
Color	see selected configuration
housing	Gray cast iron
Weight	55,00 Kg

Description

Product description
Worm gearbox with three-phase asynchronous motor to IEC standard (EN 60034/IEC 60072) from the COMBIGEAR S product range, suitable for a wide range of drive tasks in industrial environments.

Features

High-quality product - Made in Germany
Directly mounted three-phase motor
Compact design and universal mounting form - hollow or solid shaft, foot and flange version
Suitable for operation with frequency inverter
Simple spare parts procurement thanks to identification via serial number

Scope of delivery

Gearbox ready for installation and filled with lubricant to suit the installation position
Motor with ready-to-connect terminal box (with terminal diagram)
Transport eyelet

Data blisters and drawings (German only)

Data and dimension sheet
