A szállítási idő lerövidítése

A megrendelés leadásakor ellenőrzik a végtermékhez szükséges alkatrészek elérhetőségét és a gyártási lehetőségeket. A megerősítést követően a rövidített szállítási időn belül felár ellenében expressz gyártás is lehetséges.

A burkolat kialakítása

A következő házváltozatok állnak rendelkezésre:

1. 1.A - felnyomható változat, gumipufferrel történő rögzítés ajánlott (lásd az alkatrészeket).

1. 2.B - felnyomható kivitel - mint az A, plusz csavarkör a hajtómű kimenetének mindkét oldalán lévő menetes furatokkal.

1. 3.C - C karimás változat - a sebességváltó oldalsó kimeneti karimára történő felszereléséhez.

Méretek: lásd a méretlapot

Beépítési pozíció

A kenőanyag mennyiségének meghatározásához a beépítési helyzetre van szükség.

A különböző beépítési pozíciók jelölései a következő ábrán láthatók.

Shaft design

1 outer ring
2 Clamping screws
3 Inner ring
4 Hub
5 Shaft
6 Grease-free

Additional housing and shaft options

Double seal on the output shaft:

Depending on the available installation space, a combination seal with one NBR and FKM sealing lip each or two sealing rings in NBR and FKM design are used.

Advantages:

• - Optimum sealing properties at high operating temperatures thanks to FKM seal

• - Good sealing properties at low temperatures due to NBR seal

• - Better protection against high levels of soiling thanks to 2 seals (the outer seal also has a dust lip)

• - High level of safety and improved stability against oil leaks thanks to additional sealing lip

Use is recommended for

• - Critical installation positions

• - Where there are special requirements for the reliability of the seal

Reinforced bearing of the output shaft

With this option, the permissible radial forces for the output shaft can be increased.

Further information on determining the radial force and the permissible values for

standard and reinforced bearings in the PDF document Notes on selecting options

Rubber buffer for housing

Selection for slip-on version A. For elastic mounting (torque support) of the geared motor. Suitable for the hole on the front of the gearbox housing.

Mounting kit for hollow shaft

for mounting "customer shafts" with and without collar.

Further information in the PDF document Notes on selecting options

Protective cover for hollow shaft

Only possible with slip-on version B and flange version C. Fastening on existing threaded holes on the gearbox output.

Second shaft end

Standard version - without

Second shaft end - cylindrical shaft with keyway

Dust and water protection

Selectable options:

IP55 - dustproof, protection against water jets (standard)

IP65 - dust-tight, protection against water jets

IP65 with brake - as before, but with additional brake version in IP65

IP code for the degree of protection in accordance with DIN EN 60529, 60034-5,

First code number: Protection against ingress of foreign bodies

Second code number: Protection against ingress of water with harmful effects

Voltage/frequency

Selectable options:

230/400V/D/Y, 50Hz (standard)
Possible applications: In star connection (Y) directly on 400V mains, in delta connection (D) on frequency inverters with output voltage 230V/3~ or on frequency inverters with output voltage 400V/3~ and operation with 87Hz characteristic curve

400/690V/D/Y, 50Hz
Possible applications: In delta connection directly on the 400V mains, and on frequency converters with output voltage 400V/3~, star-delta start-up with switches or contactors

230/400V/D/Y, 50Hz // 460V/Y, 60Hz

290/500V/D/Y, 50Hz (up to 4kW possible)

500V/D, 50Hz (from 5.5 to 45kW possible)

Motor protection

The following options are available for monitoring the winding temperature of the motor:

a) 1 set of PTC thermistors - for monitoring with PTC thermistor tripping device or frequency inverter

b) 1 set of temperature switches (bimetal) - for monitoring e.g. with motor protection relay

The selection of one of these options is recommended when operating the geared motor on the frequency inverter, as reduced speeds and the associated lower cooling capacity can cause the motor to overheat.

Brake

The available brake types with max. possible braking torques are displayed for selection.

The following additional information is required to specify the brake:

Brake voltage

a) 230V/50Hz/1~

b) 400V/50Hz/3~

c) 24V (DC)

Braking torque at the drive motor (multiplication by the transmission ratio i results in the braking torque at the output shaft),

Manual release for the mechanical release of the brake via a lever, e.g. for adjustment or maintenance

Further information and technical data on the brakes can be found in the PDF document Notes on selecting options

Color shade

Other colors are also available on request for larger quantities.

Lubricant

The following lubricants can be selected as an option:

0 Ambient temperature

1) Load capacity O=normal, +=high, ++=very high

2) Ageing resistance O=normal, +=high, ++=very high

If option 2 is selected, protection class IP65 must also be selected!

Válvula de purga

Para despresurizar la caja de cambios. Alivia los anillos de estanqueidad y evita fugas.

Versión estándar a partir del tamaño F3 de la caja de cambios.

Cubierta de ventilador con techo protector

Cuando se instala verticalmente, la cubierta impide la entrada de cuerpos extraños o líquidos.
entrada de cuerpos extraños o líquidos.

Orificio de evacuación de la condensación
Dependiendo de la posición de instalación del motor, los orificios de condensación se encuentran en la parte inferior
del motor. Los orificios de purga de condensación vienen cerrados de fábrica y deben abrirse para purgar la condensación.
drenar la condensación.

Conexión a tierra externa

Segunda placa de características, suministrada suelta

Versión UL/CSA, con certificado combinado

Versión con homologación/certificado combinado que cumple tanto la normativa estadounidense como la canadiense.
normativas

Etiquetado CEL
Similar a la etiqueta energética de la UE, la etiqueta energética de China (CEL) es una etiqueta que indica el consumo de energía de un producto.
consumo energético de un producto. La etiqueta contiene información sobre la clase de eficiencia energética (de 1 a 5) y el
consumo de energía. La etiqueta está disponible para motorreductores de 0,75 a 45 kW.

Versión CCC
La Certificación Obligatoria China (CCC) es un sistema de certificación válido en la República Popular China.
El certificado está disponible para motorreductores de 0,12 a 1,1kW.
