Motor choke

Motor choke

Manufacturer/Type: Hitachi DWSM2-00380-0.464
Item no: 14696

Selected configuration

The product can only be ordered online in standard configuration (see technical data).
Options may be available on Request possible.

226,00 EUR
268,94 EUR incl. VAT plus Shipping costs

Technical data

Nominal voltage400V/50Hz/3ph
Rated current38 A
Rated motor power18,5 kW
Inductance0.464 mH
ISO classF
Protection classIP00
Dimensions(WxHxD) 190x200x100mm
Weight 7,00 Kg

Description

  • Motor chokes reduce the current ripple in the motor and enable longer motor cables. Protect the insulation of the motor winding.
  • Air-gap choke according to VDE 0570-2-20
  • Power loss 36W
  • Vacuum impregnated
  • Max. ambient temperature 50°C
  • Can also be used for 230V (Attention: The specified rated motor power is a guide value for 400V, design according to rated current for 230V!)
  • Product can be used regardless of manufacturer

Data blisters and drawings (German only)
Data and dimension sheet
Download
