Voltage

230/400V/D/Y, 50Hz (standard for motors up to 3.0kW)
Possible applications: In star connection (Y) directly on 400V mains, in delta connection (D) on frequency inverters with output voltage 230V/3~ or on frequency inverters with output voltage 400V/3~ and operation with 87Hz characteristic curve

400/690V/D/Y, 50Hz (standard for motors from 4.0kW)
Possible applications: In delta connection directly on the 400V mains, and on frequency inverters with output voltage 400V/3~, star-delta starting with switches or contactors

500V, 50Hz
The winding is designed for motors up to 4.0kW in 290/500V/D/Y, 50Hz as standard and from 5.5kW in 500/865V/D/Y 50Hz.

Protection class

IP code for the degree of protection in accordance with DIN EN 60529, 60034-5,
First code number: Protection against ingress of foreign bodies
Second code number: Protection against ingress of water with harmful effects

Selectable options:

IP55 - dust-protected, protection against water jets (standard)
IP56 - dustproof, protection against strong water jets
IP65 - dust-tight, protection against water jets
IP66 - dust-tight, protection against powerful water jets

Terminal box position

Up to size 132, the terminal box position can be varied by screwing the feet over (top, right or left)

Selectable options from size 160:

• top (standard)
• right
• left

The terminal box position is defined by looking at the output shaft side of the motor.

Example "Terminal box right"

Motor protection

The following options are available for monitoring the winding temperature of the motor:

• 1 set (3 pcs.) of PTC thermistors - for monitoring with PTC thermistor tripping device or
  Frequency inverter (standard)
• 1 set (3 pcs.) of temperature switches (bimetal NC contacts) - for monitoring e.g. with
  Motor protection relay
• Resistance temperature sensor PT100 - PT100 is a platinum resistance thermometer, which at
  0°C has a defined resistance value of 100 ohms and is used for precise temperature measurement.
• Resistance temperature sensor PT1000 - PT100 is a platinum resistance thermometer that has a defined resistance value of
  0°C has a defined resistance value of 1000 ohms and is used for precise temperature measurement.

The selection of one of these options is recommended when operating the motor on the frequency inverter, as the motor may overheat at reduced speeds and the associated lower cooling capacity.

Bearing

Locating bearing n-side
Motors up to size 132 have floating bearings on both sides as standard. Optionally, a fixed bearing can be selected on the n-side to absorb axial forces.

Reinforced bearing
From size 160, a reinforced bearing with NU bearing on the output side (d-side) is possible for use where increased lateral forces occur (e.g. due to belt drives).

Relubrication device d- and n-side
Possible from size 160, for simple relubrication of the motor bearings. The relubrication device is standard from size 315.

Insulated bearing n-end for frequency converter operation
Measure to prevent bearing currents during operation on the frequency inverter possible from size 250.

Colour scheme

Colour shade

Standard colour RAL7024 - Graphite grey

Attachments and accessories

Fan cover with protective roof
Designed to prevent foreign objects from falling into the fan and to protect against water ingress. Used for motors with vertical installation position.

Forced cooling fan
For use with speed-controlled drives. The forced cooling fan installed in place of the standard fan cowl ensures sufficient cooling even at "very low" speeds. Multi-connection voltages: 230V/50Hz/1~ and 400V/50Hz/3~, protection class IP55
Attention - overall length of the motor increases!

Standstill heating
Prevents condensation even under extreme climatic conditions
Possible from size 80. Connection voltage: 230V/50Hz

Design/regulations

CE/UKCA (standard) - Mark of conformity that confirms that a product fulfils the applicable safety, health and environmental requirements of the EU or the United Kingdom.

UL/CSA version with combined certificate - Version with combined approval/certificate that complies with both US and Canadian regulations.

CCC version - The China Compulsory Certification (CCC) is a certification system valid in the People's Republic of China.

CEL labelling - Similar to the EU energy label, the China Energy Label (CEL) is a label for the energy consumption of a product. The label contains information on the energy efficiency class (1 to 5) and energy consumption.
